Use
It applies to LDPE, PP, EVA, EAA, and other composite materials and BOPP, PET, aluminum foil, the Web, Lin Mo substrate, such as cloth, bags made of high-level for food, medicine and packaging industries.
And the performance characteristics of
1, the use of adjustable-rate branch die.
2, Lin Mo-three-roll device, to ensure the quality of Lin Mo-and long-term high-speed operation.
3, the host out of the use of Frequency Control.
4, admission, release tension volume using magnetic brake, clutch control.
5, with a sophisticated system of gas and electricity portfolios, joint security operation and design.
6, use a leak-turned-duplex, to achieve non-stop refueling aircraft.
7, the second leak-turned-duplex used to achieve non-stop refueling aircraft.
8, is expected to adopt land-bit duplex Torque Motor rotation, to achieve non-stop refueling aircraft.
机型
|
TL-600
|
TL-800
|
TL65-YT21000
|
复合最大宽度
|
600mm
|
800mm
|
1000mm
|
放卷卷材
|
ф500mm
|
ф500mm
|
ф500mm
|
第二放卷卷材 |
ф450mm
|
ф450mm
|
ф450mm
|
卷芯内径 |
ф76mm
|
ф76mm
|
ф76mm
|
最高淋复速度 |
80m/min
|
80m/min
|
80m/min
|
螺杆直径
|
ф45mm
|
ф65mm
|
ф90mm
|
长径比
|
28:1 |
28:1
|
28:1 |
机器重量
|
10000kg |
12000 kg |
15000 kg |
外形尺寸
|
9700×7000×2000mm
|
10000×7500×2300mm |
10300×8000×2600mm
|
|
